Control System: Show voltage, frequency, currency, speed, hours etc, when low/over speed, Battery charger fail ; Low oil pressure; High water temperature; Starting failure; Loss of speed signal; will alarming and urgent shut down.
|
1.Engine:
|
Brand-new engine.
|
|
2.Alternator:
|
Brand new brushless alternator , single bearing , IP23 , H insulation class.
|
|
3.Base Frame:
|
Heavy duty steel channel base frame.
|
|
4.Radiator:
|
With safety guard.
|
|
5.Vibration Damper:
|
Vibration damper between Engine/Alternator and base frame.
|
|
6.Breaker:
|
3-pole output manual circuit breaker as standard, 4 pole for option.
|
|
7.Controller:
|
Deepsea , Smartgen & Mebay for option.
|
|
8.Silencer:
|
Heavy duty industrial type silencer with flexible bellow,elbow.
|
|
9.Battery:
|
Brand high capacity sealed maintenance free battery c/w battery cables.
|
|
10.Fuel Tank:
|
8 hours base fuel tank.
|
|
11.Tool Kit & Manuals:
|
Standard tool kits and complete operation/maintenance/manuals for Generator/Engine/Alternator/control
|
|
Diesel Generator
|
|||
|
Genset Model
|
DAC-DS185
|
Engine
|
With DOOSAN Engine
|
|
Phase
|
3 Phase
|
Alternator
|
Brushless Self-excited
|
|
Frequency(HZ)
|
50/60HZ
|
Speed
|
1500/1800rpm
|
|
Voltage
|
110/220/380/400
|
Rated Current
|
8.3A-2160A
|
|
Cooling Mode
|
Water Cooling
|
Oil Drive
|
Direct Injection
|
|
Noise Level
|
75db 7meters away
|
Starting Mode
|
Electric Start
|
|
Brand
|
Sinba-Generator/Customized
|
IP
|
IP22-23
|
|
Type
|
Silent/Open/Trailer.,etc
|
Insulation Class
|
F/H
|
|
Fuel Tank
|
Base Fuel Tank/External Fuel Tank
|
Filters
|
Air Filter,Oil Filter and Fuel Filter
|
|
Output Factor
|
COS=0.8
|
Mode of Connection
|
3-Phase 4-wire or Y mode
|
|
Contronal Systerm
|
Show voltage, frequency, currency, speed, hours etc, when low/over speed, Battery charger fail ; Low oil pressure; High water
temperature; Starting failure; Loss of speed signal; will alarming and urgent shut down |
||
The company’s products mainly include ST, STC series of brush synchronous generators, WQDG series of equal power AC synchronous generators, WQXB series of harmonic excitation brushless synchronous generators, SZC series of welding generators, TFW2, STF series of brushless AC synchronous generators. The company’s products have applied for a number of national patents, and passed the 1SO9001:2000 international quality management system certification, the European Union “CE” certification, the products are popular all over the country, exported to Southeast Asia, the Middle East, South America, Africa, Europe, the United States and other countries and regions, and widely praised by customers.
Sinba-Generator, located in Fuzhou, China, is committed to be an excellent and reliable one-stop generator supplier. Our products include alternators, quiet diesel generators, open diesel generators.
